BA – Electric Cargo
Introducing Our Electric Cargo Auto – Versatility Meets Efficiency Uncover the future of cargo transportation with our adaptable Cargo Auto, engineered for peak performance in both open and closed body configurations
Key Features
I
Battery Type: Fueled by a LiFePo4 battery.
I
Battery Capacity: An impressive 48V, 200Ah (10Kw).
I
Charging Time: A swift 4 hours under standard conditions.
I
Battery Life: A dependable 2000 cycles
I
Powertrain: Harnesses 9.5Kw peak power and 45 Nm peak torque, featuring a direct drive transmission
I
Performance: Attains a top speed of 50 km/h with a certified range of 145 km, Typical driving range around 132Km
I
Dimensions: Open body: 2025mm x 1510mm x 390mm Closed body: 2025mm x 1510mm x 1679mm
Loadability : As Per The Requirement
BA Cargo: Electric: Smart X
Vehicle Specifications
| Motor Type | PMSM |
|---|---|
| Max. Speed | 50 kmph |
| Rated Power | 8.0 kW 72V |
| Peak Power | 12.9 kW |
| Range/Per Charge(kms) | 175* with 200Ah |
| Gradient | 15 Deg | Chassis |
| Suspension | Coil Spring |
| Wheel Size | 4.5 - 12 |
| Brake System | Hydraulic Drum | Dimensions (L*W*H) |
| Overall | 3000*1500*2100mm |
| Ground Clearance | 140 |
| Loading Capacity | 750 kgs |
| Full Cargo Box | 1590*1900*1640mm(172 CFT) | Electrical |
| Speedometer | Digital |
| Charger Volt & Time | 86.4 V &4 hrs (Approx.) |
| Battery Chemistry | LFP |
| Controller Volt | 60-90 V |
| Head light | LED |
BA Cargo Auto: Electric: Cargo Smart
Vehicle Specifications
| Motor | |
|---|---|
| Motor Type | BLDC |
| Max. Speed | 25 kmph |
| Rated Power | 1.5 kW 48V |
| Peak Power | 2.0 kW 48V |
| Range/Per Charge(kms) | 95* with 100Ah |
| Gradient | 10 Deg | Chassis |
| Suspension | Coil Spring |
| Wheel Size | 4.00 - 10 |
| Brake System | Hydraulic Drum | Dimensions (L*W*H) |
| Overall | 2820*1000*1790mm |
| Ground Clearance | 170 |
| Loading Capacity | 350 kgs |
| Half Loader | 1425*997*330mm |
| Full Cargo Box | 1425*1000*1100mm(55 CFT) | Electrical |
| Speedometer | Digital |
| Charger Volt & Time | 58.4 V &3-4 hrs (Approx.) |
| Battery Chemistry | LFP |
| Controller Volt | 42-58 V |
| Head light | LED |
Cargo Electric: Pickup
SPECIFICATIONS:
| Color | Yellow, Blue, Red, Green, Blue (Metallic Optional) |
|---|---|
| Size | 2750 X 995 X 1750 mm |
| Motor | 48V 1000W High Power |
| Max Power Output | 2000 Watts |
| Controller | 2000 Watts |
| Max Power Output | 2000 Watts |
| Controller | 24 Tube Controller 50amps, 24 Mosphets |
| Differential | 33"Differential |
| Tyres | 3.75 X 12 |
| Front Suspensions | 43 Mm Telescopic Hydraulic With Spring |
| Rear Suspensions | 6 Plate Heavy Duty Leaf Spring |
| Brakes Front Rear | Lever Operated Drum Type Foot Paddle Operated Drum |
| Loading | Open body / Closed body option |
| Parking Brake | Mechanical Hand Lever Operated |
| Chassis | Heavy Duty Tubular Type Structure |
| Battery | 110 Ah |
| Charging Time | 6-7 Hrs. |
| Charger | 3 Pin Ac Plug, Input Voltage 170-300 Vac, 15 Amps |
| Stepney | Tyre Size 3.75 X 12 Standard |
| Speed | 25-30 Kmph |
