Diesel - Victory Plus Loader
Diesel – Victory Plus Loader
SPECIFICATIONS:
| Emission Standards | BS-VI |
|---|---|
| Loading Capacity | Offset Steering: 378 Kg | Handlebar: 450 Kg |
| Brakes | Drum |
| Suspension | Front: Coil Spring; Rear: Leaf Spring |
| Driving Mode | Front: Coil Spring; Rear: Leaf Spring |
| Battery | Lead Acid 12 V |
| Starting System | Electric Push Button |
| Fuel Used | Diesel |
| Average | 25 Kmpl |
| Fuel Tank Capacity | 10.25 Ltr. |
| Engine Type | e-Di 599 WD |
| Bore | 91.3 |
| Stroke | 91.3 |
| Cubic Capacity | 597.7 |
| Max Output | 7.0 Kw |
| Max RPM | 3850 RPM |
| Max Speed | 52 Kmph |
| Gear Box | Constant Mesh |
| Clutch | Wet Multiplate |
| Kerb Weight | 477 Kg |
| Gross Vehicle Weight | 995 Kg |
| Min. Ground Clearness | 135 mm |
| Wheel base | Offset Steering: 2060 mm | Handlebar: 2034 mm |
| Rear Wheel Track | 1250 mm |
| Overall Length | Offset Steering: 3139 mm | Handlebar: 3125 mm |
| Overall Width | Offset Steering: 1491 mm | Handlebar: 1470 mm |
| Overall Height | Offset Steering: 1491 mm | Handlebar: 1470 mm |
